| Dimensions | Ø415 x 303 mm (Ø16.34 x 11.93″) |
| Weight | Without Mount: 1.3 kg (2.87 lb) With Mount: 1.8 kg (3.97 lb) |
| Enclosure Characteristics | Aluminum / UV Stabilized Polycarbonate |
|
| Processor | Quad-Core ARM Cortex A7 |
| Memory | 256 MB DDR3 |
| Networking Interface | 10/100/1000 Mbps Ethernet RJ45 |
| RF Connections | Internal |
| Max. Power Consumption | 11W |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 😎 |
| Power Supply | 24VDC, 0.5A Gigabit PoE Adapter |
| Supported Voltage Range | 22 to 26VDC |
| ESD/EMP Protection | Air/Contact: ± 24kV |
| Operating Temperature | -40 to 60° C (-40 to 140° F) |
| Operating Humidity | 5 – 95% Noncondensing |
| Certifications | FCC, IC, CE |
|
| Power | Flashing White: Bootup in Progress White: System Ready, Ubiquiti® Internet Service Provider (UISP™) Not Configured, Not Connected Flashing Blue: System Ready, UISP Configured, but Cannot Connect Blue: System Ready, UISP Configured and Connected |
| Ethernet | Flashing Blue: Ethernet Traffic Detected |
| 5G | Blue: Active Connection |
| 60G | Blue: Active Connection |
|
| OS | airOS® |
| Operating Modes | PtP |
| Ubiquiti Specific Features | Integrated 60 GHz and 5 GHz Radios, Discovery Protocol |
| Security | WPA2 AES Only |
| Dashboard | Yes |
| Wireless Settings | Yes |
| Network Settings | Yes |
| System | Yes |
| Services | UISP, Ping Watchdog, Web Server, SSH Server, NTP Client, System Log, Device Discovery |
| Tools | Antenna Alignment Tool, Discovery Utility, Traceroute, Speed Test |
| Minimum Software Requirements | Any Modern Web Browser |
|
| Operating Frequency* | | US/CA | U-NII-1 | 5150 – 5250 MHz |
|---|
| U-NII-2A | 5250 – 5350 MHz | | U-NII-2C | 5470 – 5725 MHz | | U-NII-3 | 5725 – 5850 MHz | | 57,000 – 66,000 MHz | | Worldwide | 5150 – 5875 MHz
57,000 – 66,000 MHz |
|---|
* Depends on regulatory region. |
| Max. Conducted TX Power | 25 dBm (5 GHz) |
| Channel Bandwidth | | 60 GHz | 2160 MHz | | 5 GHz | 20/40/80 MHz |
|
| Management Radio | | US/CA | 2412 – 2462 MHz | | Worldwide | 2412 – 2472 MHz |
|
| Antenna Gain | |
|
| 5 GHz TX Specifications | | Data Rate | Avg Power
(dBm) | Tolerance
(dB) |
|---|
| 1x BPSK (1⁄2) | 25 | ±2 | | 2x QPSK (1⁄2) | 25 | ±2 | | 2x QPSK (3⁄4) | 25 | ±2 | | 4x 16QAM (1⁄2) | 25 | ±2 | | 4x 16QAM (3⁄4) | 25 | ±2 | | 6x 64QAM (2⁄3) | 24 | ±2 | | 6x 64QAM (3⁄4) | 22 | ±2 | | 6x 64QAM (5⁄6) | 22 | ±2 | | 8x 256QAM (3⁄4) | 21 | ±2 | | 8x 256QAM (5⁄6) | 21 | ±2 |
|
| 5 GHz RX Specifications | | Data Rate | Avg Power
(dBm) | Tolerance
(dB) |
|---|
| 1x BPSK (1⁄2) | -95 | ±2 | | 2x QPSK (1⁄2) | -95 | ±2 | | 2x QPSK (3⁄4) | -93 | ±2 | | 4x 16QAM (1⁄2) | -90 | ±2 | | 4x 16QAM (3⁄4) | -86 | ±2 | | 6x 64QAM (2⁄3) | -83 | ±2 | | 6x 64QAM (3⁄4) | -77 | ±2 | | 6x 64QAM (5⁄6) | -74 | ±2 | | 8x 256QAM (3⁄4) | -69 | ±2 | | 8x 256QAM (5⁄6) | -66 | ±2 |
|
